Building Specifications

Overall Building Area: 139,750 sq. feet

Individual Areas:

Arena: 79,750 sq feet

Theater: 38,500 sq feet

Classrooms: 21,500 sq feet

Ticket Office: Located in the main lobby

Restrooms: Arena and Lobby Locations

Concessions: Arena and Lobby Locations

Lobby: Large open area perfect for novelty sales, booth sales, and receptions.


1,389 spaces available within 2 blocks

Bus parking

Large drop-off area

Loading Dock (Arena):

Access to Event Floor

Door Size: 19' h x 15' w

Dock Depth: 26'

Portal Size: 19' h x15 ' w

Vomitory Access Portal: 11’h x 8’w

Area Amenities:


760 hotel rooms within Sevier County


33 Restaurants within Sevier County

Prop/Scene Shop/Loading dock (Theater):

Door Size 10’h x 8’w

Dock Height – 4’h

Prop/Scene Shop – 78’d x 24’w

Available Equipment:

Portable Basketball Floor


Telephone (local & long distance access)

Bicycle Barricade

Tensa Barricade

Standard Sound System

Portable Stage


Standard Lighting Package


Note: Other equipment may be provided upon requests.

Available Services:

Fire Marshall


Crowd Management

Medical Personnel

Guest Services




Light Crew

Sound Crew

Stage Hands

Spotlight Operators

Ticket Office

Arena specifications

Capacity: 4,144 seats

Floor size: 196' x 108' (21,168 sq ft open floor space)

Height: 60' ceiling 43' low steel clearance

Dressing rooms: 4 dressing/locker rooms

Production: The Sevier Valley Center has the ability to enhance most shows including: spot lighting, sound and staging.


Arena Area: 79,750 square feet


Two full service concessions stands located on the North end inside the arena.


Large men’s and women’s restrooms located South end inside the arena.


Brand-Stage Right

Deck Size: 4' x 8'

Maximum Stage Size: 40' x 60'

Height Range: 48”- 76" even numbers

Number of stair units: 2

Show Power:

Lighting: 400 amp (3 phase)

Sound: 200 amp (3 phase)

Shore Power: 2 – 200amp (3 phase)

***Other power available upon request

Sound Mix and Booth Equipment:

Yamaha 32-channel main mixing console

2 – Tascam CD player / Tape deck

Digital signal processor w/ built in compressor and limiter

Telex Intercom (2 channel)

Theater Specifications

Total Theater Seating

816, additional disabled seating available

lower Sections:

Seats: 557

Balcony Seating Section

Seats: 259


Stage Dimensions

Fly Loft Low Steel: 62’ 1”

Stage:  59’ deep x 53’ w


Number of Fly Loft Drops

Light Bars: 5

Curtain Bars: 15

Bare Bars: (47’ & 65’) – 6

Cyclorama: (25’h x 40’w) – 1

Screen: (20’h x 37’w) – 1


Fire Curtain: 1



200 amp (3 phase)

400 amp (3 phase)


10- Shure SM 58

10- Shure SM 57

 4- Shure SM81-lc


Mic Stands

14- Stands

8- Boom attachments



Soundcraft si Compact Digital 24 Chan

Built in LEXICON processor for effects



 4- Community monitors



2- 50 foot 12 channel

1 channel Telex headset communication system
